Description

Dimensions

1200 × 1000 × 145 mm (Standard Industrial Footprint, Low Profile)

Structure Type

Vented Open Grid Deck, 9-Leg Nestable Block Base

Manufacturing Process

High-Pressure Single-Piece Injection Molding

Material Option

High-Density Polyethylene (HDPE) / Polypropylene (PP)

Static Load Capacity

1,500 kg (1.5 Metric Tons, Uniformly Distributed Load)

Dynamic Load Capacity

700 kg (0.7 Metric Tons, Uniformly Distributed Load)

Racking Load Capacity

Floor Staging, Nestable Storage & One-Way Export Use

Entry Type

4-Way Entry for Forklifts & Manual Hydraulic Pallet Jacks

Color

Customized （Blue, Green, Black, Orange......）

Weight

8.0 kg (Reinforced Heavy-Duty Profile)

Reinforced Single-Piece Injection Molding:

Molded in a single shot using high-density polyethylene (HDPE). Features reinforced support columns and thick-walled structural ribbing to deliver superior impact resistance and long-term durability without weak mechanical welds.

Nestable Space-Saving Layout:

The open 9-leg block layout allows empty pallets to nest inside one another when stacked. This maximizes warehouse floor storage density and drastically reduces return-freight transport volume during empty backhauls.

True 4-Way Universal Handling Access:

Free from bottom connecting runners, providing completely unobstructed 4-way entry for motorized forklifts, electric stackers, and standard manual hydraulic hand jacks from any direction.

Vented Open Grid Deck Architecture (145mm Profile):

The open lattice grid design promotes continuous air circulation, prevents moisture retention under stored goods, and allows fast water drainage while maintaining structural stiffness at an 8.0 kg tare weight.

Hygienic & ISPM-15 Exempt Export Standard:

100% waterproof, chemical-resistant, and impervious to rot, pests, and biological growth. Fully exempt from ISPM-15 heat treatment and fumigation mandates for fast, hassle-free international customs clearance.
