Description

Dimensions

1200 × 1100 × 150 mm (1211 Wide Industrial Footprint)

Structure Type

Vented Open Grid Deck, 3-Runner Base (3 Bottom Skids)

Manufacturing Process

High-Pressure Single-Piece Injection Molding

Material Option

High-Density Polyethylene (HDPE) / Polypropylene (PP)

Static Load Capacity

4,000 kg (4 Metric Tons, Uniformly Distributed Load)

Dynamic Load Capacity

1,000 kg (1 Metric Ton, Uniformly Distributed Load)

Racking Load Capacity

Floor Storage, Selective Racking & Roller Conveyor Compatible

Entry Type

4-Way Entry for Forklifts & Manual Hydraulic Pallet Jacks

Color

Customized （Blue, Green, Black, Orange......）

Weight

13.5 kg

1200x1100 mm (1211) Expanded Footprint:

Engineered with a wide 1200×1100 mm footprint, providing an increased deck surface area optimized for larger unitized loads, chemical drums, and specialized industrial packaging.

Single-Piece High-Pressure Injection Molding:

Molded in a single shot using high-density polyethylene (HDPE). The seamless, unitized structure eliminates mechanical joints and weak points, delivering exceptional impact resistance and structural longevity.

3-Runner Load Distribution Base:

Configured with three full-length bottom skids that provide balanced stability on factory floors, smooth transition over automated roller conveyors, and reliable support during racked storage.

Vented Open Grid Deck Architecture:

The engineered lattice grid design maintains structural stiffness at a 13.5 kg deadweight. It facilitates active airflow under cargo, prevents moisture accumulation, and enables easy washdown cleaning.

Universal Handling Accessibility:

Provides smooth 4-way access for motorized forklifts and reach trucks, as well as 2-way entry through the runner openings for standard manual hydraulic hand jacks.

Hygienic & ISPM-15 Exempt Export Standard:

100% moisture-proof, chemical-resistant, and impervious to pests, biological rot, and bacteria. Fully exempt from ISPM-15 heat treatment and fumigation mandates for seamless global logistics.
